INNOLINQ – lead-free Plug QUICK-CONNECT and MULTI-GRIP 16A 5p 400V 6h IP54
INNOLINQ – lead-free Plug QUICK-CONNECT and MULTI-GRIP
16A 5p (3P+N+PE) 400V ( 200/346-240/415V~) 6 h IP54
Frequency: 50 and 60Hz
Colour code: red RAL 3000
Contacts: the contacts are brass, the contact carrier is made of high temperature resistant material
Maximum conductor size: 2,5 qmm
Material of enclosure: Polyamide
Connection system: Screw less terminal
Cable entry: Cable gland
Colour of appliance: Collar red RAL 3000
Cable gland dark grey RAL 7012
Housing cover dark grey RAL 7012
Height of device: 160 mm, Width of device: 71 mm, Depth of device: 78 mm
Other technical features: This product is without any lead, MULTI-GRIP cable gland with gasket and integrated strain relief
Screwless housing connection with snap fastening
For cable diameter from 10 up to max. 21 mm
Product description
| BALS Product number | 200 Snro: 2419103 |
| BALS EAN | 4024941345934 |
| Product category | INNOLINQ, Pistotulpat, Pistotulpat ja kojevastakkeet, Voimapistokytkimet ja -rasiat |
| Number of poles (P) | 3P+N+PE |
| Number of poles (P99) | 5 |
| Position of earth contact | 6 h |
| Voltage acc. EN 60309-2 | 400 V |
| Degree of protection | IP 54 |
| Connection design | screwless spring terminals with KONTEX-ULTRA contact |
INNOLINQ – lead-free Plug QUICK-CONNECT and MULTI-GRIP
16A 5p (3P+N+PE) 400V ( 200/346-240/415V~) 6 h IP54
Frequency: 50 and 60Hz
Colour code: red RAL 3000
Contacts: the contacts are brass, the contact carrier is made of high temperature resistant material
Maximum conductor size: 2,5 qmm
Material of enclosure: Polyamide
Connection system: Screw less terminal
Cable entry: Cable gland
Colour of appliance: Collar red RAL 3000
Cable gland dark grey RAL 7012
Housing cover dark grey RAL 7012
Height of device: 160 mm, Width of device: 71 mm, Depth of device: 78 mm
Other technical features: This product is without any lead, MULTI-GRIP cable gland with gasket and integrated strain relief
Screwless housing connection with snap fastening
For cable diameter from 10 up to max. 21 mm
